1. Tough, compact rough Stivuitor de teren 2500kg with the 2WD system.
2. Steering Axle designed for the off-road truck with swing angle up to 10°, Self -locking shaft. suitable for harsh, rugged, and field muddy ground.
3. High strength Frame and high Curatenie totala for uneven road conditions.
4. Deep pattern and large-width Anvelope with good grip and skid resistance.
5. Widened Mast for a good view. Cast Steel for the drive axle.




Capacitatea nominală
2500kgCentrul de încărcare
500mmÎnălțimea de ridicare
3000mm1. Tough, compact rough Stivuitor de teren 2500kg with the 2WD system.
2. Steering Axle designed for the off-road truck with swing angle up to 10°, Self -locking shaft. suitable for harsh, rugged, and field muddy ground.
3. High strength Frame and high Curatenie totala for uneven road conditions.
4. Deep pattern and large-width Anvelope with good grip and skid resistance.
5. Widened Mast for a good view. Cast Steel for the drive axle.
| Term. Nr. | ERTF25-2WD |
| Capacitatea nominală | 2500kg |
| Centrul de încărcare (Distanta) | 500mm |
| Înălțimea de ridicare | 3000mm |
| Lungimea furcii | 1220mm |
| Fork Latime | 122mm |
| Fork Thickness | 50mm |
| Mast Tilt Angle (F/R) | 8/12° |
| Consolă frontală | 545mm |
| Baza roților | 1850mm |
| Max Viteza de ridicare (încărcare completă) | 450mm/s |
| Viteza maximă de conducere(No Load) | 22km/h |
| Max.Gradulabilitate (Full load) | 17% |
| Deplasare | 2.98L |
| Transmisie | Hydraulic |
| Service Greutate | 4650kg |
| Lungime cu furca | 2940mm |
| Lățimea totală | 1550mm |
| Inălțime totală(Mast Raised) | 4350mm |
| Înălțimea când catargul nu este ridicat | 2185mm |
| Înălțimea protecției deasupra capului | 2210mm |
| Min. Raza de intoarcere | 2910mm |
| Min. Curatenie totala | 220mm |
| Banda de rulare din față | 1250mm |
| Banda de rulare din spate | 1205mm |
| Front Tyre | 12-16.5-14PRmm |
| Rear Tyre | 27x10.5-15PRmm |
| Frână de mână | Pedala hidraulica |
| Tip frana | M-Hand |
